Rudder 7.0 release notes

Rudder 7.0 is currently in release candidate phase.

Rudder 7 will be supported for at least three months after next major release, and for 18 to 24 months with a subscription.

Its main features are :

  • A redesigned technique editor, more flexible, especially on the reporting and compliance side.

  • A dedicated configuration DSL for Rudder, with a transpiler to compile it into configuration code for our supported agents.

  • A new visual identity, including a new logo and new colors.

As a major release, 7.0 also comes with improvements in Rudder core architecture, to improve reliability and performance and prepare the ground for future exiting features.

New visual identity

Rudder 7.0 adopts our new visual identify. New colors and a new logo refreshing the previous design.


Setup guide on first connection

On first connection, the first admin user will now be guided by a setup wizard, allowing to configure the Rudder account directly.


New features for policy configuration

Dedicated configuration DSL for Rudder

We now have our own dedicated configuration DSL. This gives more flexibility in the way the configurations are defined, allows to define configurations directly as code, and easily share techniques.

This language is declarative and focuses on the policies correctness, by validating as much as possible during policy generation.

This language is compiled (or more precisely transpiled) into configuration code by a new rudderc program written in Rust.

We will give more details in a dedicated blog post soon.

Configure_NTP state technique() {
  package("ntp").absent("","","")
  package("chrony").present("latest","","") as package_present_chrony
}

Redesigned rules page

The rules page has been rewritten, following our new UI scheme (initiated with the groups page). Is is now based on a tree on the left and a visualization and edition zone with tabs on the right, which will avoid a lot of scrolling compared to the previous layout, and will present information in a more structured manner.


Reproducible and versioned policies

This part is a first step, the ultimate goal being to make the configuration policies fully reproducible (like in reproducible builds), i.e. to be able to explore and/or apply the configuration of any point in the past. This requires archiving the full history of inventory, properties, etc.

We also want to be able to mix different versions of the same item (e.g. of one directive), to allow progressive deployments of changes.

The 7.0 release contains:

  • New APIs exposing historization of techniques and directives. This means a full history of the item’s revisions.

  • An API to link a rule to a previous version of a directive

  • An API to link a specific version of a technique to a rule

  • Full inventory historization to allow tracking changes in the context.

Group methods in the technique editor

Techniques can now contain blocks which are groups of methods with a common condition, and the ability to configure compliance computing logic. Blocks can even be nested, and drag-and-drop works as usual.


It is possible to use one of three variants for compliance computation:

  • Sum of reports: previous behavior, use reports from all methods and compute the compliance proportionally

  • Worst report: take the worst outcome of the block as compliance for the whole block. This case has to sub-cases for reporting accuracy:

    • Count the whole block as one report (with the worst outcome) to give it the weight of a single method

    • Give the report the weight of the number of methods in the block (but still with the worst outcome only)

  • Focus on one method: Use the outcome of a specific method as outcome for the block

This allows getting more comprehensive compliance reports, with more meaningful numbers.

Disable reporting for a method in the editor

It is now possible to disable reporting for any method, and hence ignore it in the compliance. This is particularly useful for methods used as tests, for example if you want to test the present of a package with Package present, and use it as a condition to trigger other actions. Instead of having to resort to Condition from command for every test, you can now use any existing method directly.

Technique drafts

You can now have multiple technique drafts, give them a name and access them in the techniques list. This allows switching context without losing what you were doing.


Hide secret values in the interface

We added a new feature allowing to define secret variables, which means their value will be provided at creation, but not re-displayed in the interface afterwards. This allows preventing the involuntary display of passwords in Rudder interface.

Untitled

New system integration features

Easy setup of external PostgreSQL database

The server roles have been removed in favor of a simpler mechanism based on settings in the application configuration file. It is now easy to use an external PostgreSQL database with a Rudder server.

Prometheus endpoint in relayd

relayd, the component handling agent-server communication, now has a prometheus endpoint, including:

  • information about handled reports and inventories

  • information about reports parsing and insertion timings

  • information about the relayd process itself

# HELP rudder_relayd_inventories_total Agent inventories
# TYPE rudder_relayd_inventories_total counter
rudder_relayd_inventories_total{status="forward_error"} 1
rudder_relayd_inventories_total{status="forward_ok"} 23
# HELP rudder_relayd_managed_nodes_total Managed Nodes
# TYPE rudder_relayd_managed_nodes_total gauge
rudder_relayd_managed_nodes_total 54
# HELP rudder_relayd_reports_processing_duration_seconds Reports processing
# TYPE rudder_relayd_reports_processing_duration_seconds histogram
rudder_relayd_reports_processing_duration_seconds_bucket{le="0.005"} 1804
rudder_relayd_reports_processing_duration_seconds_bucket{le="0.01"} 1688
rudder_relayd_reports_processing_duration_seconds_bucket{le="0.025"} 1926
[...]

This is a first step, and more observability tooling will continue to get added in next versions.

Augeas for advanced configuration file editions

Augeas is a framework providing a tree-like view of a lot of different configuration file formats (through syntax definitions called ``lenses''). This unified interface allows hassle-free advanced editions. Augeas is now embedded with the agent when not available as a system dependency.

Configurable ports for agent-server communication

The ports used for both communication channels (by default 443 and 5309) are now fully configurable. This will make setups in constrained environments easier. It is now also easy to use different ports and certificates for public HTTP used for Web and public API access and agent-server internal communications.

Improvements in agent-server communication security

We now have a consistent homogeneous security mechanism across both communication channels, with the removal of syslog communication and the automatic setup of HTTPS certificate verification. We use Trust On First Use by default, but you can pin server keys at node provisioning too.

AlmaLinux, Rocky Linux and Oracle Linux officially supported

With the move of Red Hat to CentOS Stream (and the end of life of CentOS 8) for the end of the year, other alternatives have emerged or gained popularity. As a consequence, we now have full support (including relay and server) for AlmaLinux, Rocky Linux and Oracle Linux.

Rudder server OS compatibility update

We added server support for Debian 11 (agent support was added in 6.2) and dropped SLES 12, RHEL/CentOS 7 and Debian 9, following our usual maintenance policy.

Under the hood

These items will are directly visible from the users, but help us keep Rudder reliable and extensible.

Improved agent CLI

The agent comes with a more readable rudder agent info output.


Configure script for the agent

We added a configure script for the agent build. This makes it more flexible (compared to our previous static Makefile) and adding support for new platforms becomes a lot easier.

We also improved our C hardening flags on modern compilers with fstack-protector-strong and D_FORTIFY_SOURCE=2 when possible, in addition to existing full relro and pie.

Frontend continues to transition to Elm

Elm has been our language of choice for frontend work for its great reliability and maintainability for a few years, and the transition is continuing with the technique editor rewrite (from AngularJS) and the new rules page.

rudder-relayd updated to tokio 1.0

rudder-relayd, the component handling communications with agents on server and relays is written in Rust and more precisely based on tokio, a fast and reliable asynchronous runtime. It has been migrated from tokio 0.1 to the 1.0 version, which comes with the (not so) Rust async/await syntax. It provides better development experience, better performance (with a new scheduler), and long-term maintenance of the library for 5 years minimum.

More efficient compliance computations

Compliance computations and display has been made more efficient, by using caches for both computed compliance and expected reports. It lowers the number of expensive database queries, and makes compliance computations much faster.

relayd also now handles more steps of reports handling, which is possible thanks to the syslog reporting removal. This lowers the load on the webapp and database and makes the whole process more efficient.

Improved Continuous Integration

Our code tests, which all run on our Jenkins server also responsible for building our packages, were migrated from manually configured jobs to Jenkinsfile code (for example in the main rudder repository). This allows defining the tests along with the code, and eases jobs maintenance across branches.

Tests are now all run automatically on every pull requests (except for heavy multi-platform tests which only run daily on maintained branches).


In addition we improved our test suite in most repositories, with linters for various ecosystems (shellcheck, pylint, etc.), and added automated checks for known vulnerabilities in our dependencies across various ecosystems. Most tests now run in Docker containers defined by Dockerfiles in the repositories, allowing for more consistent and reproducible test environments.

Refactored server system techniques

Server system techniques are the part of system techniques that handle configuration and management of the server components (webapp, relayd, ldap server, etc.). We did a major refactoring of these techniques, which have been split in separate techniques for each configured service, for improved reliability and maintainability.

Dependencies upgrades

As usual in our major releases, most dependencies have been upgraded. In particular, we now require PostgreSQL ≥10 for Rudder servers.

Installing, upgrading and testing

Supported operating systems

This version provides packages for these operating systems:

  • Rudder server and Rudder relay: Debian 10-11, RHEL/CentOS/Alma/Rocky 8, SLES 15, Ubuntu 18.04 LTS and 20.04 LTS

  • Rudder agent: all of the above plus Debian 9, RHEL/CentOS 7, SLES_12

  • Rudder agent (binary packages available with a subscription) : Debian 5-8, RHEL/CentOS 3-6, SLES 10-11, Ubuntu 10.04 LTS-12.04 13.04-15.10 LTS-14.04 LTS-16.04, Windows Server 2008R2-2019, AIX 5-6-7, Solaris 10 & 11, Slackware 14

Read more about supported operating systems in the documentation.
